Sink Rolling Seam Welding Machine

This Equipment is specially designed for welding the stainless steel sink bowl and sink board together.When it work,the workpiece turn around by the even speed,the worker hold and support it manually.

PRODUCT SERIES:

Product Center

Sink Producing Line

KEYWORDS :

sink seam welding

stainless steel sink welding

kitchen sink welding

sink producing line

Inquiry

DESCRIPTION

Description
This Equipment is specially designed for welding the stainless steel sink bowl and sink board together.When it work,the workpiece turn around by the even speed,the worker hold and support it manually.
sink seam welding machine have two types: semi-automatic type sink welding machine and Full automatic CNC type sink welding machine.
sink seam welding machine is the second step of sink producing line.

Main Features:
1.There are two types of Welding Power Source : AC Spot Welding or Medium Frequency inverter DC spot welding;
2.Welding wheel adopt three-phase infinitely adjustable-speed drives,convenient to welding speed adjusting,the two welding wheels have the same tangential speed;
3.Adopt adjustable stroke cylinder,to avoid collision damage between upper and lower welding wheel;
4.Arm length can be designed according to the length of the Sinks;

Main Technical Parameters

Item Model	Rated Capacity	Rated Primary Voltage	Rated Frequency	Maximum Short Current	Electrode Stroke	Welding Speed	Electrode Pressure	Motor Power Source	Motor Power	Cooling Water Flow	Weight
Item Model	KVA	V	Hz	A	mm	M/min	KN	V	W	L/min	Kg
FN-100	100	380	50/60	20000	50	0.6-2	4.7	3-380V	150	30	880
FN-150	150	380	50/60	26000	50	0.6-2	6.1	3-380V	150	40	1050
FN-200	200	380	50/60	31000	50	0.6-2	6.1	3-380V	150	40	1250
