2D Wire Bending Machine

Servo drive, stable performance, automatic straightening, wire feeding, forming, cutting and record number

PRODUCT SERIES:

KEYWORDS :

Wire Bending Machine

2D wire forming

2D wire bending

basket bending

bending and welding

Main Features:
1.Servo drive, Stable performance;
2.High precision, no noise;
3.Easy to operate,adopt special microcomputer control,intelligent forming,high efficiency,save electricity;
4.Automatic straightening, wire feeding, forming, cutting and record number;
5.Wire feeding wheels, straightening wheels, forming wheels adopt the German high quality alloy, after vacuum heat treatment ,the high abrasion resistance and long service life;
6.Suitable for forming Various 2D shapes for all kinds of metal ( such as steel, iron, stainless steel and aluminum wire, etc. )

Main technical Parameters:
1.Motor Power：4.0~15KW
2.Wire Diameter：2~6mm, 4mm~8mm.5-10mm
3.Speed：40~80m/min
4.Machine Dimensions：2300x1600x1400mm or custom-made。
5.Machine weight：1500KG

Applications:
